Description
Individual flow sensor for most common applications
SonoSensor™ 30 is an ultrasonic flow sensor designed for heating, cooling or combined heating/cooling applications in medium sized local and district energy systems. Combined with the InfoCal™ 9 energy calculator it offers normal compact meter functionalities for medium sized hydronic applications.
The sensor is MID Class II certified.
Technical data
- Size: DN15 – DN100 | Qp 0.6-60 m3/h
- Temperature | Pressure: 5-130°C | PN16/25
- Types: Flow sensor (heat, cool)
- Approvals: MID class II B+D (heating)
- Flow sensor cable length: 1.2m | 2.5m | 5.0m
- Power: Battery AA-cell 3.6V | mains unit 24V AC | 230 V AC
- Communication: Pulse output acc. to EN1434-2, type OD
- Protection class: IP65 (IP67 upon request)
Features and benefits
Offers a 12 year battery lifetime lowering
the replacement costs
Measures volume every 1 sec. increases measurement accuracy
Insensitive to dirt lowering the needs for replacing the sensor
Low pressure loss
